Siemens 5SL6102-7 Miniature Circuit Breaker – 2A, 1-Pole, C Curve, 6 kA
The Siemens 5SL6102-7 miniature circuit breaker is a 1-pole, 2 A, C-curve MCB with 6 kA switching capacity for residential and infrastructure installations. Designed for reliable AC protection up to 400 V.
The Siemens 5SL6102-7 miniature circuit breaker from the SENTRON series is engineered for precise protection of electrical installations in residential, commercial, and infrastructure environments. Designed with a 1-pole configuration, C-curve tripping characteristic, and a rated operational current of 2 A, this MCB ensures dependable response to overload and short-circuit conditions in low-voltage distribution systems.
Built on the proven 5SL miniature circuit breaker design, the device supports AC operation up to 400 V supply voltage and offers a high switching capacity of 6 kA according to EN 60898 and IEC 60947-2. Its insulation voltage ratings of 250 V (single-phase) and 440 V (multi-phase) ensure compatibility with modern low-voltage architectures. The breaker also delivers a mechanical service life of 10,000 cycles, reinforcing its reliability for long-term technical installations.
The 5SL6102-7 supports conductor cross-sections from 0.75 to 25 mm² with a tightening torque range of 2.5–3 N·m, enabling secure and flexible wiring options. With IP20 protection (when conductors are connected) and a compact 18 mm width, it integrates easily into DIN-rail systems. For additional information, refer to our electrical protection devices category or consult the Siemens Industry Mall.
Technical Specifications – Siemens 5SL6102-7
| Brand | SENTRON |
| Product Type | Miniature circuit breaker |
| Series | 5SL miniature circuit breakers |
| Number of Poles | 1 |
| Tripping Characteristic | C |
| Mechanical Service Life | 10,000 switching cycles |
| Overvoltage Category | III |
| Degree of Pollution | 2 |
| Insulation Voltage (AC, single-phase) | 250 V |
| Insulation Voltage (AC, multi-phase) | 440 V |
| Type of Voltage | AC |
| Rated Operational Current | 2 A |
| Rated Supply Voltage (AC) | 400 V |
| Max Operating Voltage (AC, multi-phase) | 440 V |
| Max Operating Voltage (DC) | 72 V |
| Frequency | 50 Hz |
| Protection Class | IP20 (with connected conductors) |
| Switching Capacity (EN 60898) | 6 kA |
| Switching Capacity (IEC 60947-2) | 6 kA |
| Energy Limitation Class | 3 |
| Power Loss per Pole | 1.2 W |
| Suitable for | Residential buildings / infrastructure |
| Touch Protection | Yes |
| Halogen-Free | Yes |
| Sealable | Yes |
| Silicon-Free | Yes |
| Supplementary Devices Installable | Yes |
| Conductor Cross-Section (solid) | 0.75–25 mm² |
| Conductor Cross-Section (stranded) | 0.75–25 mm² |
| Conductor Cross-Section (finely stranded, ferruled) | 0.75–25 mm² |
| Tightening Torque | 2.5–3 N·m |
| Height | 90 mm |
| Width | 18 mm |
| Depth | 76 mm |
| Installation Depth | 70 mm |
| Modular Width Units | 1 |
| Mounting Position | Any |
| Net Weight | 120 g |
| Surrounding Temperature Influence | Periodically +55°C, max 95% humidity |
| Ambient Temperature (operation) | -25°C to 45°C |
| Ambient Temperature (storage) | -40°C to 75°C |
| Reference Code (DIN EN 61346-2) | F |
| Reference Code (IEC 81346-2) | F |
Key Features
- 1-pole C-curve miniature circuit breaker for 230/400 V AC systems
- High switching capacity: 6 kA according to EN 60898 and IEC 60947-2
- Robust mechanical service life of 10,000 cycles
- Wide conductor cross-section compatibility up to 25 mm²
- IP20 protection with connected conductors
- Compact 18 mm DIN-rail design for modular distribution boards
- Halogen-free, sealable, silicon-free construction
For professional procurement, installation planning, or project integration, our technical department is available to support your requirements for Siemens SENTRON circuit protection solutions.
